MINI is a compact all-in-one dental 3D printer that combines printing and curing functions into a single system to simplify the workflow.
- Produces a crown in just 15 minutes
- Ensures 18 μm accuracy
- Features a minimal footprint, making it easily portable from one location to another
- Supports dual wavelengths (385 nm and 405 nm)
| PRINTING TECHNOLOGY | LCD |
| XY AXIS PRECISION | 18 μM |
| RESOLUTION | 9 K |
| MAX PRINTING SPEED | 60 MM/H |
| LAYER THICKNESS | 0.01 – 0.1 MM |
| PRINTING METHOD | U DISK / WI-FI |
| SLICING SOFTWARE | PIONEXT BOX (WINDOWS 7/8/10 64-BIT, MACOS) |
| RATED VOLTAGE | 100–240 V, 50/60 HZ |
| RATED POWER | 120 W |
| NET WEIGHT | 4.86 KG |
Micrometric Precision for Outstanding Results
With an 18 μm XY-axis precision and 10 μm Z-axis precision, MINI delivers an exceptional level of detail. Perfect for producing bridges, crowns, and veneers with ultra-thin 0.3 mm margins. It ensures extremely accurate and well-defined results.
Effortless Clinical Mobility
Designed to move with you, MINI ensures maximum convenience within the clinic. It can be easily moved between rooms, supporting flexible chairside applications and optimizing daily workflows.
Total 2-in-1 Efficiency
The MINI printer offers an innovative fully integrated 2-in-1 printing and curing solution for a faster, more efficient, and seamless workflow.
Dual Wavelength Technology
Thanks to its 385 nm and 405 nm dual-wavelength light source, MINI provides extended compatibility with a wide range of dental resins. This versatility allows users to work with different materials in an efficient and reliable way, always ensuring high-quality results.
Doubled Screen Lifespan
Compared to conventional LCD screens, MINI integrates advanced amber-screen technology, designed to significantly increase resistance to UV exposure. The result is superior protection against premature aging, a lifespan up to twice as long, and consistent, reliable performance even under the most intensive daily use.
Dual Resin Tanks for Maximum Versatility
MINI is equipped with two resin tanks, designed to provide operational flexibility and consistent results across multiple applications. This setup makes it easy to adapt to different materials and clinical needs, improving the overall workflow efficiency. In addition, it supports the rapid production of crowns and bridges in just 15 minutes, significantly optimizing daily clinical operations.
WASH MINI: Compact Cleaning, Professional Results
WASH MINI is the compact ultrasonic cleaning machine designed to work in perfect synergy with the MINI 3D printer. Ideal for cleaning small 3D prints, it ensures an efficient and controlled process. Easy to use and integrate into the daily workflow, it makes every post-printing stage simple, fast, and consistently reliable.
Quick-Release Module for Maximum Operational Efficiency
The build platform and resin tank are designed with a quick-release system, allowing for instant material changes and simplifying daily maintenance operations. This intelligent module reduces wear and deformation caused by scraping, ensuring consistently stable, smooth, and reliable printing performance over time.
Code 500.0099
